Fig. 67. Setup - Outputs - Options - DI Options.
3.3.5.3. DI OPTIONS (digital input options)
The DI Option you select applies to all outputs. This
option overrides any Setpoint/Setback values entered in
the Schedule.
1. Press the  button to display the DI Option selec-
tions.
2. Use the  and  buttons to highlight DISABLE,
SETBACK, or IGNORE.
Default: DISABLE
3. Press the  button to accept the value and display
the SHOW RT option.
When the digital input (DI) closes, all outputs follow the DI
option value (Disable, Setback, or Ignore):
• DISABLE disables the outputs; relays return to
de-energized state and Mod outputs return to 0%
output.
• SETPOINT forces the control to the setpoint
temperature
• SETBACK enables a setback temperature value to be
programmed for each output and forces the control to
the setback temperature.
— To program the Setback temperature with Reset,
Refer to Fig. 34 on page 15.
— To program the Setback temperature without
Reset, Refer to Fig. 43 on page 18.
• ENABLE energizes all relays and MOD outputs to
100%. Use this option carefully.
•DHW: If a reset curve is being used, then the
controlled setpoint becomes the maximum setpoint
(either SP MAX A1 or BOILR MAX). If a reset curve is
not being used, then DI closure for DHW has no effect.
• IGNORE causes the digital input to have no effect on
the Relay or Mod outputs.
Fig. 68. Setup - Outputs - Options - Show Runtime.
3.3.5.4. SHOW RT (show run time hours)
1. Press the  button to display the Show RT values.
2. Use the  and  buttons to select YES or NO.
Default: YES
3. Press the  button to accept the value and return to
the Options menu.
Selecting YES shows the RT (run time) hours for each
relay on the home screen displays.
NOTE: Run times can be reset to zero for each indi-
vidual relay. You must do this for each relay
that you want to reset to zero. Refer to
“3.3.6.4. RESET RT (run time)” on page 31.
SETUP
OUTPUTS
OPTIONS
DI OPTS
SETUP
OUTPUTS
OPTIONS
DI OPTS
SELECT DI
OPTIONS
FOR
OUTPUTS
DISABLE
SETPOINT
SETBACK
ENABLE
DHW
IGNORE
M24346A
SETUP
OUTPUTS
OPTIONS
SHOW RT
SETUP
OUTPUTS
OPTIONS
SHOW RT
USE
RUNTIME
FOR
RELAYS
YES
NO
M24347
