higher), it is possible to perform a “remote calibration” using the VA301C menu:
Statistics
Calibration
7. Network
1. Using the navigation arrows, access the VA301C’s menu
2. Scroll through the menu options and select option 7. Network
3. Scroll through the Network options screens to the last screen and select the Calibration option
The Calibration screen contains four (4) lines of information:
Status: Normal
Set Zero
Set Span 246 PPM
Calib 007 S301M
Line 1: Indicates the mode (Calib, meaning calibration), the (Modbus) address of the device to calibrate
(007) and the type of device to calibrate (S301M)
Line 2: Indicates the status (Normal or In calib ) of the specified device
Line 3: Displays the function to perform (Set Zero)
Line 4: Displays the function to perform (Set Span) and the span gas concentration value (246 ppm)
1. On the first line, scroll to the device address and press Enter
2. Scroll through the devices to display the desired device* and press Enter to select.
3. The second line displays the device status
4. Scroll to select the desired function, Set Zero to set the device’s zero, and press Enter to select.
Status: Normal
Set Zero
Set Span 246 PPM
Calib 007 S301M
5. Upon pressing Set Zero, the controller requests confirmation.
6. Press Enter to confirm or Esc to cancel. If confirmed, the controller sets the S301M’s Zero. This takes
only a few moments and the display returns to the default calibration screen.
7. To calibrate the device, scroll to Set Span** and change the span gas calibration value using this
procedure;
Status: Normal
Set Zero
Set Span 200 ppm
Calib 001 : S301M
a. Using the right arrow, move the cursor to xxx PPM (span value field). Press Enter to select the field
(it’s editable when flashing).
b. Use the up or down arrows to increase or decrease the value, press Enter to validate the new value.
c. Move the cursor back to Set Span and press Enter to start the calibration.
The device Span is being calibrated. The screen will display the device status as “In calib...” until the
calibration is complete.
*The device must be configured in the VA301C’s database in order to be included in the device addresses
displayed on screen.
**When selecting Set Span, make sure that the device has been exposed to the appropriate calibration gas.
