2 Product Specification
Rotary actuators 135 • M140 • M150 • M180
Operating instructions Version 2.0 - June 2012 9
2.5 Technical data
Type M135, M150 M140, M180
Supply voltage:
230 V AC + 6% -10%
24 V AC ± 10%
230 V AC + 6% -10%
24 V AC ± 10%
Power consumption
M135 = 9 VA
M150 = 12 VA
M140 = 55 VA
M180 = 26 VA
Weight 2.5 kg 3 kg
Dimensions See technical
data sheets
Frequency 50/60 Hz ±5% 50/60 Hz ±5%
Ambient temperature 0 to +50°C 0 to +50°C
Protection type IP 54 IP 54
Operation mode S1-100% ED M140 = S3-50% ED
M180 = S3-60% ED
Torque /
Set time at 50 Hz
M135 = 35 Nm / 130 s/90°
M135 = 15 Nm / 70 s/90°
M150 = 50 Nm / 130 s/90°
M150 = 40 Nm / 70 s/90°
M140 = 50 Nm / 10 s/90°
M180 = 80 Nm / 130 s/90°
M180 = 80 Nm / 70 s/90°
Input signal Y Three-point Three-point
Limit stop cut-off Slow-down, infinitely variable max. 320°
table 1 Technical data
