Wing Installation continued
1. Slide the wing halves together on the wing tube.
2. Install the plastic center cap on the center of the wing.
3. Connect the aileron servos to the Y-harness. The left and right aileron servos can be connected to either side of
the Y-harness.
4. Be sure not to pinch the wiring between the wing and fuselage and when you install the wing, .
5. Tighten the four 12mm x 3mm machine screws to secure the wing assembly to the fuselage.
6. Disassemble in reverse order.
