HORNER XL4 - Page 57

MAN0964-14-EN_XL4_XL4P_UM
N o v e m b e r 1 0 , 2 0 2 1 P a g e 57 | 194
Table 6.2 – %SR Registers – Master %SR Table
Register
Default I/O
Name
Description
Min-Max
Values
Program
(Read/Write)
Display
(Read/Write)
%SR193.2
TRUE to switch programs, FALSE when
complete
Read Only
Read Only
%SR193.3
TRUE if executing program is
temporary test
Read Only
Read Only
%SR193.4
TRUE during last scan of switched-from
program
Read Only
Read Only
%SR193.5
TRUE during first scan of switched-to
program
Read Only
Read Only
%SR193.6
TRUE to revert to FLASH and delete all
RAM; FALSE when complete
Read Only
Read Only
%SR193.9
TRUE if error in temporary program
Read Only
Read Only
%SR194
Battery Charge Temp Low
*XL+ Only – Frequency in MHz
Read Only
Read Only
%SR195
Battery Charge Temp High
*XL+ Only – in degree centigrade
Read Only
Read Only
%SR196
Charging State
NOTE: Refer to MAN1142 for more
details on Rechargeable Batteries
0=Waiting
1=Normal Charging
2=Hot Charge
3=Hot Charge
4= Battery Hot
5= Cold Charge
6=Battery Cold
7=No Battery
8= Not Charging (after 8 hours of
charging)
9= CPU Hot, not charging
10 Battery voltage <2V, not charging
11= First 2 minutes Init Wait (Not
Charging)
0 to 11
Read Only
Read Only
%SR197
Charging Current Max mA
Read Only
Read Only
%SR198
Battery Voltage is mV
Read Only
Read Only
%SR199
Reserved
%SR200
InitRD Version ( /100)
Read Only
Read Only
%SR201-205
Linux Kernel version: ASCII, 10
characters
Read Only
Read Only
%SR206-
208
Reserved
%SR209.3
WebMI Server Status. Bit 3 is ON if
server running.
Read Only
Read Only
%SR209.4
WebMI User Logged in Status. Bit 4 is
ON if 1 or more users logged in.
Read Only
Read Only
%SR209.9 -
209.16
Number of Users. Shows in upper byte
in decimal format.
Read Only
Read Only
