1. Drive with the tractor and machine up to the
seed wagon and apply the brake.
2. Connect the seed wagon on the adjustable
drawbar and secure it.
3. Connect the hydraulic lines for the fan.
4. Connect lighting, automatic tram line system
and ISOBUS.
5. Relieve the support, fold it up and secure it
with the bolt. Secure the pin with the cotter
pin.
Variant 2:
Connecting the seed wagon to the tractor
¾ See operating instructions for the seed wagon.
Connecting the machine to the seed wagon
1. Drive with the tractor and seed wagon up to
the machine and apply the brake.
2. Coupling the machine:
- Adjust the height of the drawbar by crank-
ing the support so that the machine can
be picked up.
- Engage the machine.
- Insert the bolts and secure them.
3. Connect the hydraulic lines, see chapter
Hydraulics.
4. Connect lighting and ISOBUS.
5. Relieve the support and dismantle it.
6. Secure the support in the parking position
with bolt and cotter pin.
Support in parking position
30
