Unhitching the seed wagon from the machine
1. Position the emptied machine at a suitable
location and set the tractor brake.
2. Fold down the support and secure with bolt
and cotter pin:
3. Release the hold-down of the ball and socket
coupling.
4. Raise the drawbar by cranking on the support
until the ball has cleared.
5. Unplug the hydraulic lines.
6. Unplug the lighting, automatic tram line sys-
tem and ISOBUS and hook in the bracket.
Attach the cover caps if so equipped.
7. Clean the seed hopper.
8. Lock the seed hopper cover.
9. Clean the metering units.
Unhitching the machine from the seed wagon
1. Position the machine at a suitable location
and set the tractor brake.
2. Fold down the support and secure with bolt
and cotter pin:
3. Adjust the height of the drawbar by cranking
on the support and remove the bolt on the
drawbar eye.
4. Depressurise the hydraulic lines and discon-
nect them.
Unhitching the seed wagon from the tractor
¾ See operating instructions for the seed
wagon.
