Cutting discs hydraulic cylinder with aluminium clips
¾ Lifting the discs.
¾ Remove the clips from or place them on the
hydraulic cylinders of the discs.
Working without cutting discs
Working without the discs is possible depending
on the eld conditions.
¾ Lift the tines and discs all the way.
¾ Disable the hydraulics of the disc system with
the rotary spool valve.
Vorlage ed Mai 06
DatumEn t w.DateinameZeichnungsnummerMaschine Zeichnung
Maschine 00380943
00380943
0
I
Rotary spool valve for disc system with sticker
