Horton C2150 User Manual

APPENDIX C CODE DISPLAYS
Codes are arranged in alphanumeric order (NOTE: D = Display, P = Parameter, E = Error)
Open Check speed (see sect.2 step 8)
This is a Power fail Open code (see sec.14)
Open Speed (see sect. 2 step 8)
OBstruction - If door is impeaded while opening / stops displays Ob and opens in OC
Door was activated or is being held open by SW 'C' input. See App. D CN2 for wiring & LED
Close Speed see section 2 step 8
Power fail CLose see section14
Close Check speed - see section 2, step 8
Door is idle in 2 way night mode. See section 5
Door is idle in 1 way day mode. See section 5
Door is idle in 1 way night mode. See section 5
Finding Open is displayed when the door is opening while counting encoder pulses. See section 2 step 6
Finding Close is displayed when the door is closing to the fully closed position after a power failure or during learn initialization cycle see sect. 2 step 5
This is a cycle code (see foot note) from Interior Motec see appendix D CN2
This parameter is factory set - do not change without consulting the factory
This indicates the control tried to run the motor & received no response from the encoder. The run was aborted to save the fuse( functional 2.09 & up)
Provides Locking in 1 way mode (see section 7)
Turn on this parameter to save the fuse if the door is actuated while jammed or locked (see J1)
Automatic Lock Failed to lock (see section 8)
Shows lock is present (see sect. 6)
Access restricted call factory for assistance
Indicates Loss of Pulses from encoder (see section 11)
Door has not reached close monitor switch. See sect. 1 step 2. Check for obstructions. See appendix A step 2
No Lock found during initialization (see section 6)
Control is braking - door always brakes when opening. Close braking can be turned on at the [b parameter
This parameter determines stroke to open check. Adjustable from 50-90% of total stroke
Main time delay- starts when all activate and recycle inputs clear and door is fully open
Partial open delay is active when SW 'A' is on (App. D) & starts when all activate and recycle inputs have cleared & door is at partial open
Brake on recycle turned on, the control will slow door substantially before reversing on recycle
When close braking parameter is turned on, the control brakes the door after close speed - recommended for heavy doors
This indicates battery failure of C3985 monitored power failure unit - see section 14
When Auto Seal parameter is turned on, the display will change to AS and the control will try to close the door every 15 seconds
This parameter is factory set - do not change without consulting factory
Door is idle in 2 way day mode. See section 5
Control has failed - must be replaced
Brief display indicates start of Encoder test see section 11
This shows a successful Data Save. See section 3 step 10
This is a cycle code (see foot note ) from ext motec input see appendix D CN2
This is a cycle code (see foot note ) from DOWN button
Encoder Failure see section11
Door Locks (in day mode ) when this parameter is turned on. See section 7
Control failed to store parameters (control must be replaced)
Encoder Phasing error see section 11
Close Cushion speed (see section 2 step 8)
Cycle test will cause door to open and close repeatedly for test purposes
2.0483d 09-07
CODE
DISPLAY MEANING
H210.16
2.00P
P2.03
PD
2.11
2.00
PD
D
2.00
PD
2.22
2.00
P2.18
E
PD
2.05
2.00
D
E2.06
2.00
E
D2.07
2.07
2.00
D
E
2.00
D2.15
E
D
2.02
2.00
D
D
2.00
2.00
P
2.58D
P
2.15D
VERSIONTYPE
2.03P
D
P
2.00
PD 2.00
2.00
PD
PD
PD
2.00PD
2.00E
2.00PD
2.11
2.00
2.00
2.00
2.15
2.19
P2.03
D
D
D
D
E
2.00PD
E
D
P
D
2.19
2.19
2.19
