10
2. Condensing Unit
a) SRC-10H
Condenser
Receiver
Fan Motor
Headmaster (C.P.R.)
High-Side
Service Valve
Compressor
High-Pressure
Switch
Liquid Line
Connection
Suction Line
Connection
Control Low-Pressure Switch
Control Box
Safety Low-Pressure Switch
