IV. Service Diagnosis
WARNING
1. This unit should be diagnosed and repaired only by qualied service
personnel to reduce the risk of death, electric shock, serious injury, or re.
2. Risk of electric shock. Use extreme caution and exercise safe electrical
practices.
3. Moving parts (e.g., fan blade) can crush and cut. Keep hands clear.
4. CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews
are securely in place after the unit is serviced. Make sure that none have
fallen into the dispenser unit/storage bin.
5. Make sure all food zones in the icemaker and dispenser unit/storage bin are
cleanaftertheunitisserviced.Forcleaningprocedures,see"VI.Cleaning
andMaintenance."
A. Ice Production Check
To check production, prepare a bucket or pan to catch the ice and a set of scales to
weigh the ice. After the icemaker has operated for 10 to 20 minutes, catch the ice
production for 10 minutes. Weigh the ice to establish the batch weight. Multiply the batch
weight by 144 for the total production in 24 hours.
B. Diagnostic Procedure
This diagnostic procedure is a sequence check that allows you to diagnose the electrical
system and components. Before proceeding, check for correct installation, adequate
water supply (minimum of 10 PSIG, maximum of 113 PSIG) and proper voltage per unit
nameplate. Check that the 24VAC 1A fuse and the 115VAC 3A GM fuse are good. When
checking for high-voltage (115VAC), always choose a white (W) neutral wire to establish
a good neutral connection. When checking for low-voltage (secondary) (24VAC), always
choose a light blue (LBU) neutral wire to establish a good neutral connection. If the
icemakerisinalarm,see"II.C.2.LEDLightsandAudibleAlarmSafeties."
Note:EHenergizeswhen"GM"LEDturnson.CBX1ComprelayenergizesPDS.
Pressure rises in the refrigeration system and closes CLPS. MC is energized
when CLPS closes, energizing Comp and FMR.
1)Removethefrontpanel,thenmovethepowerswitchtothe"OFF"position.
2) Unplug the icemaker from the electrical outlet.
3) Remove the control box cover and access CB.
4)ChecktheS1dipswitchsettings,see"II.C.3.a)DefaultDipSwitchSettings"toassure
that they are in the correct positions. For proper operation of IS, conrm that S1 dip
switch7isinthe"ON"position.
5) Startup – "POWER OK" LED is on. Plug the icemaker into the electrical outlet, then
movethepowerswitchtothe"ON"position.Movethecontrolswitchtothe"ICE"
position.CB"POWEROK"LEDandISgreenLEDshouldbeon.Diagnosis "POWER
OK" LED:CBPOWEROK"LEDisoff.Checkforpropersupplyvoltage(115VAC)input
to the control transformer. If 115VAC is not present, check the power switch and breaker.
Next, check for proper 24VAC outpout voltage from the control transformer. Check CB
