Hoshizaki MODULAR CUBELET SERENITY SERIES FS-1022MLH-C User Manual

44
Evaporator Assembly
Evaporator Heater
Cutter
Cutter Hex Head Bolt
Extruding Head
Auger
O Ring
Seal Bolts and Washers
Socket Head Cap Screw and Split
Lock Washer
Gear Motor
Gear Motor Barrier
Lower Housing
O Ring
Mechanical Seal
Spline Coupling
Hex Bolt and Washer
Socket Head Cap Screw and Split
Lock Washer
Washer
Socket Head Cap Screw and Split
Lock Washer
Upper Bearing
(pressed into auger)
Lower Bearing
(pressed into lower housing)
Truss Head Screw
w/Rubber Washer
Fig. 7
Dowel Pin
Seal Bolts and Washers
