AC SUPPLY VOLTAGE 115/60/1
GEAR MOTOR 120 V 3 FLA 1/4 HP
OTHER 120 V 0.03A
MAXIMUM FUSE SIZE 15 A
MAX. HACR BREAKER (USA ONLY) 15 A
MAX. CIRC. BREAKER (CANADA ONLY) 15 A
MINIMUM CIRCUIT AMPACITY 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lb./day (kg/day) 70 *830 (380) 805 (365) 785 (355)
Reference without *marks 80 765 (350) 750 (340) 730 (330)
90 710 (325) *705 (320) 680 (310)
100 660 (300) 650 (295) *600 (275)
SHAPE OF ICE Cubelet
ICE QUALITY Approx. 80%, Ice (90/70°F, Conductivity 200 µs/cm)
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 1745 (5.96) 1713 (4.94)
FS-1022MLH-C & SRC-10H
ELECTRIC W (kWH/100 lbs.) 331 (1.13) 345 (1.00)
FS-1022MLH-C ONLY
POTABLE WATER 84 (12) 100 (12)
gal./24HR (gal./100 lb.)
EXTERIOR DIMENSIONS (WxDxH) 22"x16.5"x26" (560x417x657mm)
EXTERIOR FINISH Stainless Steel
WEIGHT Net 126 lb. (57 kg), Shipping 166 lb. (75 kg)
CONNECTIONS - ELECTRIC Cord Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
- REFRIGERATION Suction line 1-1/16-12 UNF Fitting (#10 PARKER)
CIRCUIT Liquid line 5/8-18 UNF Fitting (#6 PARKER)
ICE MAKING SYSTEM Auger type
HARVESTING SYSTEM Direct Driven Auger (1/4 HP Gear Motor)
ICE MAKING WATER CONTROL Float Switch
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM (Primary) Photoelctric Sensor
BIN CONTROL SYSTEM (Secondary) Mechanical Bin Control (Proximity Switch)
CONDENSING UNIT Air-Cooled Remote Condensing unit SRC-10H Required
EVAPORATOR Copper Tube on Cylinder
REFRIGERANT CONTROL Thermostatic Expansion Valve
Headmaster (C.P.R.) on SRC-10H (210 PSI)
REFRIGERANT CHARGE R-404A, 8 lb. 6 oz. (3800 g)
Icemaker: 4 oz. (113 g)
Condensing Unit: 8 lb. 2 oz. (3687 g)
DESIGN PRESSURE High 427 PSIG, Low 230 PSIG
P.C. BOARD CIRCUIT PROTECTION Fuse (1A)
GEAR MOTOR PROTECTION Fuse (3A)
LOW WATER PROTECTION Float Switch and Timer
ACCESSORIES -SUPPLIED Spare Fuse
-REQUIRED Ice Storage Bin
Condensing Unit: SRC-10H
OPERATING CONDITIONS VOLTAGE RANGE 104-127VAC
AMBIENT TEMP. 45-100°F
WATER SUPPLY TEMP. 45-90°F
WATER SUPPLY PRESSURE 10-113 PSIG
I. Specications
A. Icemaker
1. FS-1022MLH-C
Note: We reserve the right to make changes in specications and design without prior
notice.
