Hoshizaki MODULAR CUBELET SERENITY SERIES FS-1022MLH-C User Manual

54
3) Pour the sanitizing solution over the extruding head until the evaporator assembly and
thereservoirarefullandthesolutionstartstooverowintothedrainpan.
4) Remove the proximity switch from the chute assembly, then remove the chute assembly
from the icemaker.
5) Remove the packing at the bottom of the ice chute. Remove the 3 ties and the chute
insulation.
6) Remove the 2 baffles.
7) Remove the plate and the packing from the top of the ice chute, then remove the
backup bin control assembly by sliding it slightly towards the chute opening and lifting it
off.
8) Disassemble the backup bin control assembly by removing the 2 snap pins, shaft, and
actuator.
9) Soak the spout, O-ring, packings, chute, baffles, plate, and backup bin control assembly
in the sanitizing solution for 10 minutes then wipe them down.
10) Rinse the parts thoroughly with clean water.
CAUTION
If the solution is left on these parts, they will rust.
11) Replace all parts in their correct positions.
IMPORTANT
When installing the baffles, make sure that the bent surface (the one without
the studs) faces the actuator so that the bent surface can guide the ice to the
center of the actuator.
12) Replace all panels except the front panel in their correct positions. Move the control
switchtothe"ICE"position,thenplugtheunitbackin.Movethepowerswitchtothe
"ON"position,thenreplacethefrontpanelinitscorrectposition.Makeiceusingthe
solution until the icemaker stops making ice.
13)Removethefrontpanel,thenmovethepowerswitchtothe"OFF"position.Movethe
controlswitchtothe"DRAIN"position,thenmovethepowerswitchbacktothe"ON"
position. Replace the front panel in its correct position.
14) Allow the water system to drain for 5 minutes.
15)Removethefrontpanel.Movethepowerswitchtothe"OFF"position,thenunplugthe
unit from the electrical outlet.
5. Sanitizing Procedure - Final
1) Mix a new batch of the sanitizing solution.
2)Makesurethepowerswitchisinthe"OFF"position,theunitisunpluggedfromthe
electrical outlet, and the water supply line shut-off valve is closed. Remove the top
panel.
3) Remove the strap connecting the spout to the chute assembly, then remove the spout.
