c) Drain Frequency Control (S1 dip switch 4)
This unit is factory set for optimum performance with the 1-in-1 drain cycle (S1 dip
switch4inthe"OFF"position).Thissettingallowsforremovalofsedimentfromthe
evaporator without interrupting the icemaking process. An optional 1-in-12 drain cycle is
available.
S1 Dip Switch Setting
Drain Timer Interval Drain Valve Open
No. 4
OFF (1-in-1) 1 Hour 2 Seconds
ON (1-in-12) 11 Hours 45 Minutes 10 Minutes
d) Continuous Dispensing Timer (S1 dip switch 5 & 6)
DCMmodelsonly.ThedispensemodeswitchonDCMsmustbeinthe"CONTINUOUS"
position for this setting to apply. The factory setting allows ice to be dispensed
continuously as long as the dispense solenoid is activated.
S1 Dip Switch Setting
Dispense Time
No. 5 No. 6
OFF OFF No Limit
ON OFF 20 Seconds
OFF ON 60 Seconds
ON ON No Limit
e) Bin Control Selector (S1 dip switch 7)
This unit is factory set for infrared sensor bin control operation. No adjustment is
required. When used on a standard ice storage bin, the mechanical bin control may be
used instead of the infrared sensor by moving S1 dip switch 7 to the off position. In the
factory default position (S1 dip switch 7 in the on position), the gear motor delay after the
upperoatswitchclosesis30seconds.Whenthemechanicalbincontrolisused(S1
dipswitch7intheoffposition),thegearmotordelayaftertheupperoatswitchclosesis
5 seconds. WARNING! Do not place S1 dip switch 7 in the off position on dispenser
unit applications.
S1 Dip Switch
Setting
Bin Control Application Gear Motor Delay
No. 7
OFF Mechanical Bin Control (Standard Ice Storage Bins Only) 5 seconds
ON
Infrared Sensor with
Mechanical Bin Control Backup
30 seconds
