22
III. Technical Information
A. Water Circuit and Refrigeration Circuit
1. FS-1022MLH-C with SRC-10H
Overow
Reservoir
Gear Motor
Drain Valve
Expansion Valve
Water Level
Evaporator
Float Switch
Inlet Water Valve
Water Supply Line
Liquid Line
Drier
Pump-Down Solenoid Valve
FS-1022MLH-C SRC-10H
Drain Outlet
Compressor
Safety Low-Pressure Switch
Fan Motor
Condenser
Headmaster (C.P.R.)
High-Pressure Switch
Low-Side Service Valves
High-Side Service Valves
Control Low-Pressure Switch
Receiver
Strainer
Suction Line
