11
3. Icemaking Unit
Cutter
Extruding Head
Upper Bearing
Evaporator Heater
Auger
Mechanical Seal
O-Ring
Housing-Lower Bearing
Spline Coupling
Gear Motor
Hex Bolt and Washer
Evaporator
Seal Bolts and Washers
Socket Head Cap Screw
and Split Lock Washer
Washer
Socket Head Cap Screw
and Split Lock Washer
