8
Note: We reserve the right to make changes in specications and design without prior
notice.
B. Condensing Unit
1. SRC-10H
AC SUPPLY VOLTAGE 208-230/60/1 (3 Wire w/Neutral for 115VAC)
COMPRESSOR 208-230V 9.6 RLA 46 LRA
FAN MOTOR 120 V 3 A MAX
OTHER 120 V 0.5 A
MAXIMUM FUSE SIZE 20 A
MAX. HACR BREAKER (USA ONLY) 20 A
MAX. CIRC. BREAKER (CANADA ONLY) 20 A
MINIMUM CIRCUIT AMPACITY 20 A
EXTERIOR DIMENSIONS (WxDxH) 28"x23"x19" (711x280x485mm)
DIMENSIONS WITH LEGS (WxDxH) 28"x23"x36" (711x280x915mm)
EXTERIOR FINISH Galvanized Steel
WEIGHT (Approximate) Net 143 lb. (65 kg), Shipping 169 lb. (77 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- REFRIGERATION Suction Line 1 1/16"-12 UNF Fitting (#10 PARKER)
CIRCUIT Liquid Line 5/8"-18 UNF Fitting (#6 PARKER)
COMPRESSOR Hermetic, Model RS80-C2E-CAV
CONDENSER Air-Cooled Fin and Tube Type
FAN MOTOR PROTECTION Thermal Protector
REFRIGERATION PROTECTION Auto-Reset High-Pressure Switch, Manual Low-Pressure Switch
REFRIGERANT CONTROL Headmaster (C.P.R.) (210 PSI)
PUMPDOWN CONTROL Auto-Reset Low-Pressure Switch
REFRIGERANT CHARGE R-404A, 8 lb. 6 oz. (3800 g)
Condensing Unit: 8 lb. 2 oz. (3687 g)
Icemaker: 4 oz. (113 g)
DESIGN PRESSURE High 427 PSIG, Low 230 PSIG
COMPRESSOR PROTECTION Internal Protector
ACCESSORIES -SUPPLIED Leg 2 pcs.
Hex Head Bolt w/ Washer 8X16 8 pcs.
Hex Nut 8 pcs.
OPERATING CONDITIONS VOLTAGE RANGE 187-253 VAC
AMBIENT TEMP. -4-122°F
HEAT OF REJECTION 10500 BTU/hr
