Generator Synchronized
Time
0-20 min 5 min
Generator Shutdown Delay 0-20 min 5 min
Generator Exercise Mode
Interval
0-60 d 30 d
Generator Rated Max
Power
0-20000 W /
Generator High Voltage
Limit
0-280 V /
Generator Low Voltage
Limit
0-180 V /
Generator High Frequency
Limit
0-65 Hz /
Generator Low Frequency
Limit
0-59 Hz /
3. Tap “Meter Location” to configure the grid side meter. The serial number (SN) can be entered manually or
identified through scanning the QR code. If the GEN port is connected to the PV inverter, the PV side meter
also needs to be configured.
Note:
Check whether the direction of CT is correct. If the CT is reversely connected, choose the plant, tap
“Advanced Config
→
Grid Meter CT reverse
→
Enable” or “PV Meter CT reverse
→
Enable” to get the correct
sampling current, and tap “Save”.
