Table 3-1 Computer major components and their descriptions
Item Component Spare part
number
(1) Display assembly (14 inch)
NOTE: Displays are only spared at the subcomponent level. For display assembly spare part information, see Display
assembly subcomponents on page 21.
(2) Hinge cover
NOTE: For hinge cover spare part information, see Display assembly subcomponents on page 21.
Natural silver L24474-001
Pale gold L24471-001
Snow ake white L24472-001
(3) Top cover/keyboard (includes TouchPad and TouchPad top mylar; does not include TouchPad board
or TouchPad click board)
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 63.
Ash silver, not backlit L24818-xx1
Ash silver, backlit L24817-xx1
Snow ake white, backlit L24819-xx1
Snow ake white, not backlit L24820-xx1
Natural silver, backlit L48647-xx1
Natural silver, not backlit L48648-xx1
(4) TouchPad board cable L23184-001
(5) TouchPad board L24484-001
(6) TouchPad click board
NOTE: The TouchPad click board cable is available using spare part number L24485-001.
L24486-001
(7) Power connector L23188-001
(8) Hard drive (does not include bracket)
1 TB, 5400 rpm, 7 mm 762990-005
500 GB, 5400 rpm, 7 mm 778186-005
(9) Hard drive cable L23187-001
(10) Hard drive bracket L24490-001
(11) eMMC board, 64 GB
NOTE: The eMMC board cable is available using spare part number L23397-001.
L23398-001
(12) eMMC bracket L23387-001
(13) Battery
3-cell, 41 Whr, 3.6 Ahr Li-ion L11119-855
3-cell, 45 Whr, 3.9 Ahr Li-ion L56424-005
(14) USB board L24483-001
18 Chapter 3 Illustrated parts catalog
