TouchPad
Table 5-12 TouchPad description and part number
Description Spare part number
TouchPad L24484-001
Before removing the TouchPad, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Remove the rubber feet (see Computer feet on page 31).
3. Remove the bottom cover (see Bottom cover on page 33).
4. Remove the battery (see Battery on page 35).
5. Remove the TouchPad click board (see TouchPad click board on page 46).
To remove the TouchPad:
1. Peel the conductive tape o the keyboard (1).
2. Lift the TouchPad to remove it from the computer (2).
Reverse this procedure to install the TouchPad click board.
Component replacement procedures 47
