Heat sink assembly
NOTE: The heat sink assembly spare part kit includes replacement thermal materials.
Table 5-16 Heat sink assembly description and part number
Description Spare part number
Heat sink assembly, discrete (includes replacement thermal materials)
For use in models with the following processors: A9-9425, A6-9225, A4-9125 L23386-001
For use in models with the following processors: Ryzen7-3700U, Ryzen5-3500U, Ryzen3-3200U, Athlon
300U
L23192-001
Heat sink assembly, UMA (includes replacement thermal materials)
For use in models with the following processors: A9-9425, A6-9225, A4-9125 L23385-001
For use in models with the following processors: Ryzen7-3700U, Ryzen5-3500U, Ryzen3-3200U, Athlon
300U
L23191-001
Before removing the heat sink assembly, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Remove the rubber feet (see Computer feet on page 31).
3. Remove the bottom cover (see Bottom cover on page 33).
4. Remove the battery (see Battery on page 35).
To remove the heat sink assembly:
1. If you have a model with discrete graphics:
a. In the order indicated on the heat sink, remove the six Phillips M2.0 × 4.0 screws (1) that secure the
heat sink to the system board.
Component replacement procedures 53
