MMODe
MMODe
Command Syntax:
Example:
Query Syntax:
Returned Format:
where
c marker-mode >
Example:
HP 1650B/HP 16518
Programming Reference
command/query
The MMODe (Marker Mode) command selects the mode controlling
marker movement and the display of the marker readouts. When
PATTern is selected, the markers will be placed on patterns. When
TIME is selected, the markers move on time. In MSTats, the markers are
placed on patterns, but the readouts will be time statistics.
The MMODe query returns the current marker mode.
:MACHine{l I2):lWAVeform:MMODa (OFF1 PATTern [TIME1 MSTats}
OUTPUT XXX; “:MACHINEl:TWAVEFORM:MMODE TIME”
:MACHine{l12}:TWAVeform:MMODe?
[:MACHine{ 1[2):lWAVeform:MMODe] c marker-mode > c NL>
:: = {OFFI PATTern ITIME MSTats}
10 DIM MQ [loo]
20 OUTPUT XXX;” :MACHfNEl:TWAVEFORM:MMODE?”
30 ENTER XXX; M$
40 PRINT M$
50 END
TWAVeform Subsystem
19-9
