Switch Overview
Switch Hardware Features
Reset Button
This button is used to reset the switch while it is powered on. This action clears
any temporary error conditions that may have occurred and executes the
switch self test. The Reset button is also used with the Clear button to restore
Factory Default settings.
Clear Button
This button is used for these purposes:
■ Deleting Passwords - When pressed by itself for at least three seconds,
the button deletes any switch console access passwords that you may
have configured. Use this feature if you have misplaced the password and
need console access.
This button is provided for your convenience, but its presence means
that if you are concerned with the security of the switch configuration
and operation, you should make sure the switch is installed in a secure
location, such as a locked wiring closet.
■ Restoring Factory Default Configuration - When pressed with the
Reset button in a specific pattern, any configuration changes you may
have made through the switch console, the web browser interface, and
SNMP management are removed, and the factory default configuration is
restored to the switch. For the specific method to restore the factory
default configuration, see “Restoring the Factory Default Configuration”
in chapter 4, “Troubleshooting” of this manual.
Power Connector
The 1810-24 and 1810-24G Switches do not have a power switch, they are
powered on when connected to an active AC power source. The switches
automatically adjust to any voltage between 100-127 and 200-240 volts and
either 50 or 60 Hz. There are no voltage range settings required.
Spd
(green)
On Indicates the port is operating at 1000 Mbps.
Blinking Indicates the port is operating at 100 Mbps.
Off Indicates the port is operating at 10 Mbps.
* The blinking behavior is an on/off cycle once every 1.6 seconds, approximately.
** The blinking behavior is an on/off cycle once every 0.8 seconds, approximately.
LED State Meaning
