2-1

Installing the Switch

The HP 1810 Switches are easy to install. They come with an accessory kit

that includes the brackets for mounting the switches in a standard 19-inch

telco rack, in an equipment cabinet, and with rubber feet that can be attached

so the switches can be securely located on a horizontal surface. The brackets

are designed to allow mounting the switches in a variety of locations and

orientations. This chapter shows how to install the switches.

Included Parts

The following components ship with an HP 1810 Switch:

■ Documentation kit

■ Accessory kits:

• Quick Setup Guide

• Safety and Regulatory information

• Software License, Warranty, and Support information

1810-24 and 1810-24G Switch 1810-8 and 1810-8G Switch

Kit number 5066-0620

• three 3/4” (20-mm M4) screws for wall and

under-table mounting

• three wall anchors

Kit number 5066-2506

• two mounting brackets

• eight 8-mm M4 screws to attach the

mounting brackets to the switch

• four 5/8-inch number 12-24 screws to

attach the switch to a rack

Kit number 5064-4254

• four rubber feet

Kit number 5066-0621

• three 3/4” (20-mm M4) screws for wall

and under-table mounting

• three wall anchors

• cable tie for power cord

Kit number 5064-4254

• four rubber feet
