HP 1810-24G Installation And Getting Started Guide

A-1
A
Specifications
Switch Specifications
Physical
Electrical
1
Requires a connection to an external power adapter. The adapter automati-
cally adjusts to any voltage between 100-127 or 200-240 volts and either 50 or
60 Hz.
2
The switch automatically adjusts to any voltage between 100-127 or 200-240
volts and either 50 or 60 Hz.
3
The switch can also be powered by a PoE PD connection to Port 1. Port 1 is
an IEEE 802.3af Compatible PD (PoE Powered Device) - Class 3.
Width Depth Height Weight
1810-8 (J9800A)
20.15 cm (7.9 in) 11.8 cm (4.65 in) 4.4 cm (1.73 in) 0.35 kg (0.8 lbs)
1810-24 (J9801A)
33.0 cm (13.0 in) 17.45 cm (6.9 in) 4.4 cm (1.73 in) 1.41 kg (3.1 lbs)
1810-8G (J9802A)
20.15 cm (7.9 in) 11.8 cm (4.65 in) 4.4 cm (1.73 in) 0.38 kg (0.8 lbs)
1810-24G (J9803A)
33.0 cm (13.0 in) 17.45 cm (6.9 in) 4.4 cm (1.73 in) 1.35 kg (3.0 lbs)
AC voltage Maximum current Frequency range
1810-8 (J9800A)
1
100-240 volts 0.5A 50/60 Hz
1810-24 (J9801A)
2
100-127 volts
200-240 volts
0.4 A / 0.3 A 50/60 Hz
1810-8G (J9802A)
1,3
100-240 volts 0.5A 50/60 Hz
1810-24G (J9803A)
2
100-127 volts
200-240 volts
0.4 A / 0.3 A 50/60 Hz

HP 1810-24G Specifications

General

Switching Capacity	52 Gbps
Throughput	38.7 Mpps
Form Factor	Rack-mountable
Management	Web-based GUI
Power Supply	Internal
Layer	Layer 2
Operating Temperature	0°C to 40°C (32°F to 104°F)
Ports	24 RJ-45 10/100/1000 ports
Weight	2.27 kg (5.0 lb)
Operating Humidity	10% to 90% non-condensing
