2-16

Installing the Switch

Installation Procedure

Removing the SFPs:

Note You should disconnect the network cable from the SFP before

removing it from the switch.

Depending on when you purchased your HP SFP, it may have either of three

different release mechanisms: a plastic tab on the bottom of the SFP, a plastic

collar around the SFP, or a wire bail.

To remove the SFPs that have the plastic tab or plastic collar, push the tab or

collar toward the switch until you see the SFP release from the switch (you

can see it move outward slightly), and then pull it from the slot.

To remove the SFPs that have the wire bail, lower the bail until it is approxi-

mately horizontal, and then using the bail, pull the SFP from the slot.

Replace the protective cover on the SFP.
