HP 3PAR StoreServ 7400 2-node Service Guide

Figure 48 2.5-inch SFF disk drive
Figure 49 3.5-inch LFF disk drive
Table 19 Drive Chassis FRUs
CSR TypeQty Per ChassisDescriptionMaterial Number
Not1SPS-Enclosure Midplane 2U24 Assy683232-001
Not1SPS-Enclosure Midplane 4U24 Assy683233-001
SPS-Drive Carrier SFF SSD Assy683234-001
SPS-Drive Carrier LFF HDD Assy683235-001
SPS-Drive Carrier LFF SSD Assy683236-001
The following are CSR-A parts:
Mandatory24–480SPS-Drive HD 300GB 6G SAS 15K
M6710 2.5in HDD
697387-001
MandatorySPS-Drive HD 450GB 6G SAS 10K
M6710 2.5in HDD
697388-001
Drive Enclosure Components 57
