[:SENSe]:TINTerval Subtree (HP 53131A and HP 53132A With
S/N Prefix Below 3646)
This subtree controls the time interval (including Time Interval, Risetime,
Falltime, Duty Cycle, and Pulse Width functions) measuring capabilities of the
instrument. Refer to page 4-98, for Time Interval arming capabilities of the
HP 53132A with a serial number prefix 3646 and above.
[:SENSe]:TINTerval:ARM Subtree (HP 53131A and HP 53132A
With S/N Prefix Below 3646)
This subtree is use to synchronize the time interval start and stop arm with events.
The following combination of start/stop arming sources are valid:
STARt:SOURce STOP:SOURce Front-Panel Arming Settings
ARM DELAY
IMMediate IMMediate AUTO NONE
IMMediate TIMer AUTO TIME
EXTernal IMMediate EXTERNAL NONE
EXTernal TIMer EXTERNAL TIME
[:SENSe]:TINTerval:ARM[:STARt]:SLOPe POSitive | NEGative
Sets or queries the slope of the external start arm signal used in external arming
time interval (including Time Interval, Risetime, Falltime, Duty Cycle, and Pulse
Width functions) measurements.
A sequence of ASCII-encoded bytes: POS or NEG
• *RST: POSitive
• Only applies when [:SENS]:TINT:ARM[:STAR]:SOUR EXT is selected.
Gate & ExtArm
Query Response
Comments
Related
Front-Panel
Keys
