Chapter 2 Command Summary
Front Panel to SCPI Command Maps
Programming Guide 2-5
Input Channels Conditioning Keys to SCPI Command Map
(Cont.)
1 a. [:SENSe]:EVENt[1|2]:LEVel[:ABSolute]:AUTO ON|OFF
b
1
. [:SENSe]:EVENt[1|2]:LEVel[:ABSolute] <numeric_value> [V]
b
2
. [:SENSe]:EVENt[1|2]:LEVel:RELative <numeric_value> [PCT]
c. [:SENSe]:EVENt[1|2]:SLOPe POSitive | NEGative
d
1
. [:SENSe]:EVENt[1|2]:HYSTeresis:RELative 100 *
d
2
. [:SENSe]:EVENt[1|2]:HYSTeresis:RELative 50
d
3
. [:SENSe]:EVENt[1|2]:HYSTeresis:RELative 0 **
e
1
. [:SENSe]:EVENt2:FEED “ [:]INPut[1]”
e
2
. [:SENSe]:EVENt2:FEED “ [:]INPut2”
2 :INPut[1|2]:IMPedance <nume ric_value> [OHM]
3 :INPut[1|2]:COUPling AC|DC
4 a
1
. :INPut[1|2]:ATTenuation 1
a
2
. :INPut[1|2]:ATTenuation 10
5 :INPut[1|2]:FILTer ON | OFF
6 :INPut3:COUPling?
:INPut3:IMPedance?
__________________________
*Note, in firmware revisions 3317, 3335 and 3402, use 0.
**
Note, in firmware revisions 3317, 3335 and 3402, use 100.
Figure 2-1. Input Channels Conditioning Keys to SCPI Command
Map (Part 2 of 2)
