Chapter 3 Programming Your Universal Counter for Remote Operation
Elements of SCPI Commands
Programming Guide 3-5
3a To set the address to “15”, perform the following:
a. Press s key.
HP-IB: 03 is displayed. Note that “0” digit appears and is highlighted,
indicating that this digit will change when the
d or f arrow key is pressed.
b. Press d key.
HP-IB: 13 is displayed.
c. Press g key
HP-IB: 13 is displayed, but now the “3” digit is highlighted, indicating
that this digit will change when the d or f arrow key is pressed.
d. Press d key twice or until 15 is displayed.
HP-IB: 15 is displayed.
e. Go on to step 4.
3b To set the HP-IB mode to “TALK,” perform the following:
a. Press s key.
HP-IB: 03 is displayed. Note that “0” digit appears and is highlighted,
indicating that this digit will change when the
d or f arrow key is pressed.
b. Press d key until “TALK” is displayed.
HP-IB: TALK is displayed.
c. Go on to step 4.
4 Press Enter key.
BE SURE to press the Enter key to complete the entry.
The address/mode is now stored in non-volatile memory, and does not change
when power is cycled or after a remote interface reset.
NOTE
