HP 6000 User Manual

2-4 Removal and Replacement HP Omnibook 6000/6100
Removing the Battery
(User-Replaceable)
Required Equipment
• None.
Removal Procedure
• Slide the battery’s release latch, then lift the battery out of its compartment.
Figure 2-2. Removing the Battery
Reassembly Notes
• Insert the front (rounded) end of the battery into the battery compartment on the bottom of the
computer, and lower the back end in until it clicks into place.

HP 6000 Specifications

General

Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500, Optional discrete graphics cards
Operating System	Windows 7
Optical Drive	DVD-ROM
Network	Integrated 10/100/1000 Ethernet
Ports	USB 2.0, VGA, Serial, Parallel, PS/2, Audio In/Out
Expansion Slots	PCI, PCIe x1, PCIe x16
Power Supply	300W
