HP 6000 User Manual

HP Omnibook 6000/6100 Removal and Replacement 2-13
Removing the Display Assembly
(HP Authorized Service Providers Only)
Required Equipment
• Small Phillips screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery. Remove the secondary battery if one is
installed.
2. Remove the power button panel (page 2-11).
3. From the back of the computer, remove the two screws near the PS/2 keyboard/mouse port, and the
two near the AC adapter jack.
4. From the bottom of the computer, remove the two screws from the rear corners (closest to the back
edge).
5. Open the display. Remove the screw from the display’s ground wire, and disconnect the main
cable.
6. Remove any screws from the center hinge cover, and from the left and right hinges.
7. Lift the display off of the computer.

HP 6000 Specifications

General

Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500, Optional discrete graphics cards
Operating System	Windows 7
Optical Drive	DVD-ROM
Network	Integrated 10/100/1000 Ethernet
Ports	USB 2.0, VGA, Serial, Parallel, PS/2, Audio In/Out
Expansion Slots	PCI, PCIe x1, PCIe x16
Power Supply	300W
