HP Omnibook 6000/6100 Removal and Replacement 2-1
2
Removal and Replacement
This chapter tells you how to remove and replace the Omnibook’s removable components and
assemblies. The items marked by
in the following table are user-replaceable.
Table 2-1. Removal Cross-Reference
Battery, main (page 2-4).
Battery, CMOS (page 2-34).
Bumpers, display (page 2-12)
Cap, pointing stick (page 2-12).
Card, mini-PCI #1 (page 2-9).
Card, mini-PCI #2 (page 2-34).
Case, bottom (page 2-22).
Case, top (page 2-20).
Cover, center hinge (page 2-34).
Cover, left corner (page 2-12).
Cover, left hinge (page 2-34).
Cover, mini-PCI (page 2-12).
Cover, SDRAM (page 2-12).
Cover, right corner (page 2-12).
Cover, right hinge (page 2-34).
Covers, screw (page 2-12).
CPU module (page 2-19).
Display assembly (page 2-12).
Doors, docking (page 2-27).
Doors, PCMCIA (page 2-27).
Drive, hard disk (page 2-7).
Feet, rubber (page 2-12).
Heatsink (with fan) (page 2-17).
Keyboard (page 2-15).
Panel, sound/IR (page 2-34).
Panel, mini-PCI (page 2-34).
Panel, power button (page 2-11).
Panel, vent (page 2-34).
PCA, display interface (page 2-34).
PCA, power supply (page 2-34).
PCA, motherboard (page 2-22).
PCA, volume (page 2-34).
PCA, front antenna (page 2-34).
PCA, rear antenna (page 2-34).
Plug-in module (page 2-5).
SDRAM module (page 2-6).
Socket, PCMCIA (page 2-34).
Speaker assembly (page 2-28).
Tray, hard disk drive (page 2-7).
Caution
Always provide proper grounding when performing repairs. Without proper
grounding, an electrostatic discharge can damage the Omnibook and its
components.
Notes
Reassembly steps are the reverse of the removal steps. Reassembly notes are included at the end
of each section below.
Symbols like this throughout this chapter show approximate full-size screw outlines. You can
use these to verify the sizes of screws before you install them. Installing a wrong-size screw can
damage the unit. (The symbol at the left represents an M2.5×5mm T-head screw.)
