HP 6000 - Removing a Plug-In Module (User-Replaceable); Figure 2-3. Removing a Module; Figure 2-4. Removing a Module

HP Omnibook 6000/6100 Removal and Replacement 2-5
Removing a Plug-In Module
(User-Replaceable)
Required Equipment
• None.
Removal Procedure
1. Press the button on the module release latch, and slide the latch toward the front of the computer.
Figure 2-3. Removing a Module
2. Grasp the module and pull it out.
Figure 2-4. Removing a Module
