Power supply views
AC power supply
Figure 4 AC power supply
(1) Captive screw (2) Power switch
(3) Air outlet vent
(4) Power receptacle
DC power supply
Figure 5 DC power supply
(1) Captive screw
(2) Power switch
(3) Air outlet vent
(4) Power receptacle
Transceiver module, fiber connector, and optical
fiber views
Use an SFP or SFP+ transceiver module together with an optical fiber with LC-type fiber connector.
1 2
3
4
1 2
3
4
