Memory 4 × 2 GB DDR3
Storage media 4 GB CF card
Dimensions (H × W × D) (without rubber feet and
mounting brackets)
88.1 × 440 × 480 mm (3.47 × 17.32 × 18.90 in)
Rate AC voltage range 100 VAC to 240 VAC @ 50 Hz or 60 Hz
Rate DC voltage range –48 VDC to –60 VDC
System power consumption 160 W to 260 W
Weight 13.3 kg (29.32 lb) (without power supplies)
Operating temperature 0°C to 45°C (32°F to 113°F)
Relative humidity (noncondensing) 5% to 95%
Table 10 AC power supply specifications
Model PSR300-12A2/PSR300-12A2
Rate input voltage range 100 VAC to 240 VAC @ 50 Hz or 60 Hz
Rated power 300 W
Table 11 DC power supply specifications
Model PSR300-12D2
Rate input voltage range –48 VDC to –60 VDC
Rated power 300 W
Transceiver module specifications
The transceiver modules whose names contain MM and SM support multi-mode optical fibers and
single-mode optical fibers, respectively.
Table 12 SFP-FE-SX-MM1310-A specifications
Central wavelength 1310 nm
Transmission distance 2 km (1.24 miles)
Transmission rate 125 Mbps
Connector type Duplex LC
Fiber mode MMF
Fiber diameter 50 µm
Transmit power –19 to –14 dBm
41
