Power supply LEDs
Figure 10 AC power supply LEDs
(1) AC power input status LED
(2) AC power output status LED
Table 25 AC power supply LED description
AC OK
Off No power is input or the power supply has an input problem.
Steady green The power input is normal.
DC OK
Off No power is output or the power supply has an output problem.
Steady green The power output is normal.
Figure 11 DC power supply LEDs
(1) DC power input status LED
(2) DC power output status LED
Table 26 DC power supply LED description
Input
Off
No power is input or the power supply has an input problem.
Steady green
The power input is normal.
Output
Off
No power is output or the power supply has an output problem.
Steady green
The power output is normal.
