LED
Mark
Status
Description
Expansion slot status
LED (green/yellow)
MOD
Steady green An interface card is present.
Flashing green The hard disk is reading or writing data.
Steady yellow A failure has occurred.
Off No interface card is present.
100/1000 Base-T
out-of-band
management Ethernet
port status LED (green)
LINK/
ACT
Off No link is present.
Steady green A link is present.
Flashing green The port is receiving or transmitting data.
100/1000 Base-T
autosensing Ethernet
port status LED
N/A
Steady yellow A 100 Mbps link is present on the port.
Flashing yellow
The port is receiving or transmitting data at 100
Mbps.
Steady green A 1000 Mbps link is present on the port.
Flashing green
The port is receiving or transmitting data at
1000 Mbps.
Off No link is present on the port.
100Base-FX/1000Ba
se-X SFP port status
LED
N/A
Steady yellow A 100 Mbps link is present on the port.
Flashing yellow
The port is receiving or transmitting data at 100
Mbps.
Steady green A 1000 Mbps link is present on the port.
Flashing green
The port is receiving or transmitting data at
1000 Mbps.
Off No link is present on the port.
10GBase-R SFP+ port
status LED
N/A
Steady green A link is present on the port.
Flashing green
The port is receiving or transmitting data at 10
Gbps.
Off No link is present on the port.
