Getting Started
Entering Measurement Parameters
Scaling the
Measurement Trace
1. Press the
Cm]
key to access the scale menu.
2. To view the complete measurement trace on the display, press
AuQjscale
.
3.
To change the scale per division to 5 dB/division press
Scale/Div
@
Enter.
4. To move the reference position (indicated by the
)
symbol on the left side
of the display) to the first division down from the top of the display, press
Reference
Pusition
(?iJ
Enter. Figure 2-3 shows how each reference
position is identified.
5. To change the reference level to 0
dB,
press Reference Level @
Enter.
10
9
8
7
6
5
4
3
2
1
0
po!352b-c
Figure 2-3. Reference Positions
2-9
