Connecting the IRF member switches in one rack
Use short-haul and long-haul SFP+ cables to connect the IRF member switches (10 switches in this
example) in a rack as shown in Figure 66. The switches in the ring topology (see Figure 67) are in the
same order as connected in the rack.
Figure 66 Connecting the switches in one rack
