Fabric OS 5.x administrator guide 117
• ficonDbg dump rnid
• ficonDbg log
• ficonShow ilir
• ficonShow lirr
• ficonShow rlir
• ficonShow rnid
• ficonShow switchrnid
• ficucmd dump -A
• Other detailed information for protocol-specific problems:
• Display port data structures using the ptDataShow command.
• Display port registers using the ptRegShow command.
Identifying ports
The ficonshow rlir command displays, among other information, a tag field for the switch port. You
can use this tag to identify the port on which a FICON link incident occurred. The tag field is a
concatenation of the switch domain ID and port number, in hexadecimal format. The following example
shows a link incident for the switch port at domain ID 120, port 93 (785D in hexadecimal):
switch:admin> ficonshow rlir
{
{Fmt Type PID Port Incident Count TS Format Time Stamp
0x18 F 785d00 93 1 Time server Thu Apr 22 09:13:32 2004
Port Status: Link not operational
Link Failure Type: Loss of signal or synchronization
Registered Port WWN Registered Node WWN Flag Node Parameters
50:05:07:64:01:40:16:03 50:05:07:64:00:c1:69:ca 0x10 0x200115
Type number: 002064
Model number: 103
Manufacturer: IBM
Plant of Manufacture: 02
Sequence Number: 0000000169CA
tag: 155d
Switch Port WWN Switch Node WWN Flag Node Parameters
20:5d:00:60:69:80:45:7c 10:00:00:60:69:80:45:7c 0x00 0x200a5d
Type number: SLKWRM
Model number: 24K
Manufacturer: BRD
Plant of Manufacture: CA
Sequence Number: 000000000078
tag: 785d
}
}
The Local RLIR database has 1 entry.
switch:admin> ficonshow rlir
