Fabric OS 5.x administrator guide 93
Configuring a new SAN Director 2/128 with two domains
By factory default, the SAN Director 2/128 is configured as one 128-port switch (one domain). The
following procedure assumes that the new director:
• Has been installed and connected to power, but is not yet attached to the fabric.
• Has been given an IP address, but is otherwise running factory defaults. If this is not the case, back up
the current configuration before starting, so that you can restore it later if necessary.
• Is running Fabric OS 4.4.0 or later.
• Is running in configuration option one (one switch, FC2-16 cards installed).
Use the following procedure to add a factory-new SAN Director 2/128 to a fabric and configure it as
two 64-port switches (two domains).
1. Connect to the switch and log in as admin.
2. Issue the chassisconfig command without options to verify that the switch is configured with one
domain.
For example:
3. Issue the chassisconfig command to configure two domains. Use the -f option to suppress
prompting for uploading the configuration.
This command reboots the system. For example:
4. After the system reboots, log in again to the first logical switch (sw0) as admin.
Status Displays the status of the blade:
• VACANT: The slot is empty.
• INSERTED, NOT POWERED ON: The blade is present in the slot
but is turned off.
• DIAG RUNNING POST1: The blade is present, powered on, and
running the post-initialization POST.
• DIAG RUNNING POST2: The blade is present, powered on, and
running the POST.
• ENABLED: The blade is on and enabled.
• ENABLED (User Ports Disabled): The blade is on, but external ports
have been disabled with the bladeDisable command.
• DISABLED: The blade is powered on but disabled.
• FAULTY: The blade is faulty because an error was detected. The
reason code numbers displayed are for debugging purposes.
• UNKNOWN: The blade is inserted but its state cannot be determined.
Field Value
chassisconfig
Current Option: 1
chassisconfig -f 2
Current Option changed to 2
Restoring switch 0 configuration to factory defaults...
All account passwords have been successfully set to factory default.
Restoring switch 1 configuration to factory defaults...
All account passwords have been successfully set to factory default.
