Fabric OS 5.x administrator guide 91
Port blade compatibility
Table 16 indicates which blades are supported for each HP StorageWorks director.
Setting chassis configurations
The chassisConfig command allows you to set the chassis configuration for products that support both
single-switch (one domain) and dual-switch (two domains) operation.
Table 17 lists the supported configurations options for Fabric OS 5.x.
Table 16 Blades supported by each HP StorageWorks director
Director Port Blades
FC-16 FC2-16 FC4-16 FC4-32
Core Switch 2/64
(CP1)
Supported N/A N/A N/A
SAN Director
2/128 (CP2)
Supported Supported Supported N/A
4/256 SAN
Director (CP4)
N/A Supported Supported Supported
Table 17 Supported configuration options
Option Number of
domains
Maximum number
of ports per switch
Supported port
blades
Supported
CP blades
Notes Results
1 1 128 FC2-16, FC4-16 CP2 or CP4 CP4 fits all chassis
except the D2
chassis. Option 1
is the default
configuration for
the SAN Director
2/128.
One 128-port
switch (Blade
IDs 4, 17 on
slots 1–4, 7–10.
Blade ID 5 and
16 on slots 5, 6)
22 64/64 FC2-16 CP2 N/A Two 64-port
switches (Blade
ID 4 on slots
1–4, 7–10.
Blade ID 5 on
slots 5, 6)
32 64/64 Left side: FC2-16
Right side: FC-16
CP2 N/A Two 64-port
switches (Blade
ID 4 on slots
1–4; ID 2 on
slots 7–10.
Blade ID 5 on
slots 5, 6)
