HP Chromebook x360 User Manual

3. Disconnect the battery cable from the system board (see Battery on page 28).
Remove the display panel:
1. Open the computer to 90° (1).
2. Place suction cups in the middle on both sides of the top of the display (2).
NOTE: Be sure not to place the suction cups on the camera module.
3. While pulling the suction cups away from each other, use a tool to separate the display enough to get to
the tape (3).
NOTE: Be sure not to place the tool on the camera module.
4. On the left and right sides of the panel, grasp the tape with tweezers and roll the tweezers while pulling
the tape out from behind the panel (4).
5. Rotate the panel over and place it on the keyboard (5).
6. Peel the tape o the connector on the back of the display panel (1).
26 Chapter 5Removal and replacement procedures for authorized service provider parts

HP Chromebook x360 Specifications

General

RAM	4GB or 8GB
Operating System	Chrome OS
Graphics	Intel UHD Graphics
Convertible	Yes
Display Size	14 inches
Processor	Intel Pentium
Storage	32GB or 64GB eMMC
Display Resolution	1920 x 1080 (Full HD)
Ports	USB-C, USB-A, Headphone/Microphone combo
Wireless	Bluetooth 5.0
