1. Remove the four screw covers (1) and the four Phillips M2.5 × 7.0 screws (2) from the bottom cover.
2. Starting near the hinges, use a tool to release the bottom cover (1).
3. Remove the bottom cover (2).
To replace the bottom cover, reverse the removal procedures.
Battery
To remove the battery, use this procedure and illustration.
Table 5-3
Battery description and part number
Description Spare part number
2 cell, 47 Whr, Li-ion battery L75783-007
WARNING! To avoid personal injury and damage to the product:
● Do not puncture, twist, or crack the battery.
28
Chapter 5Removal and replacement procedures for authorized service provider parts
