16. To remove the magnets, use a tool to release the magnets from the bottom corners and side of the
panel.
To reassemble and replace the display assembly, reverse this procedure.
Top cover with keyboard
The top cover with keyboard remains after removing all other spare parts from the computer. The rst
table provides the main spare part number for the top cover with keyboards. The second table provides the
keyboard country codes.
Table 5-11
Top cover with keyboard descriptions and part numbers
Description Spare part number
Top cover with keyboard, backlit N24445-xxx
Top cover with keyboard, not backlit N24446-xxx
44 Chapter 5Removal and replacement procedures for authorized service provider parts
