HP Chromebook x360 User Manual

4. Remove the speakers from the computer (4).
To install the speaker, reverse this procedure.
I/O board
To remove the I/O board, use these procedures and illustrations.
Table 5-8
I/O board description and part number
Description Spare part number
I/O board N24428-001
I/O board cable N24422-001
Before removing the I/O board, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Disconnect the battery cable from the system board (see Battery on page 28).
Remove the I/O board:
1. Disconnect the two cables from the ZIF connectors on the board (1).
2. Remove the three Phillips M2.0 × 3.5 screws (2) that secure the bracket, and then remove the bracket (3).
3. Remove the Phillips M2.0 × 3.0 screw (4) that secures the board.
4. Remove the board from the computer (5).
I/O board
35

HP Chromebook x360 Specifications

General

RAM	4GB or 8GB
Operating System	Chrome OS
Graphics	Intel UHD Graphics
Convertible	Yes
Display Size	14 inches
Processor	Intel Pentium
Storage	32GB or 64GB eMMC
Display Resolution	1920 x 1080 (Full HD)
Ports	USB-C, USB-A, Headphone/Microphone combo
Wireless	Bluetooth 5.0
