To install the I/O board, reverse this procedure.
Heat sink
To remove the heat sink, use these procedures and illustrations.
Table 5-9
Heat sink descriptions and part numbers
Description Spare part number
Heat sink N24425-001
Before removing the heat sink, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Disconnect the battery cable from the system board (see Battery on page 28).
Remove the heat sink:
1. In the order indicated on the heat sink, remove the six Phillips M2.0 × 3.0 screws (1) that secure the heat
sink to the system board.
36 Chapter 5Removal and replacement procedures for authorized service provider parts

HP Chromebook x360 Specifications

General

RAM	4GB or 8GB
Operating System	Chrome OS
Graphics	Intel UHD Graphics
Convertible	Yes
Display Size	14 inches
Processor	Intel Pentium
Storage	32GB or 64GB eMMC
Display Resolution	1920 x 1080 (Full HD)
Ports	USB-C, USB-A, Headphone/Microphone combo
Wireless	Bluetooth 5.0
