Before removing thesystem board, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery (see Battery on page 28).
4. Remove the heat sink (see Heat sink on page 36).
5. Remove the WLAN module (see WLAN module on page 30).
Remove the system board:
1. Disconnect the following cables from the system board:
● Camera cable (ZIF) (1)
● Display cable (ZIF) (2)
● I/O board cable (reverse ZIF) (3)
● I/O board cable (reverse ZIF) (4)
● Left speaker cable (5)
● Keyboard backlight cable (ZIF) (6) (select products only)
● Keyboard cable (ZIF) (7)
● Touchpad cable (ZIF) (8)
● Right speaker cable (9)
2. Remove the three Phillips M2.0 × 3.5 screws (1) from the bracket, and then remove the bracket (2).
3. Remove the four Phillips M2.0 × 2.5 screws (3) from the system board.
38
Chapter 5Removal and replacement procedures for authorized service provider parts

HP Chromebook x360 Specifications

General

RAM	4GB or 8GB
Operating System	Chrome OS
Graphics	Intel UHD Graphics
Convertible	Yes
Display Size	14 inches
Processor	Intel Pentium
Storage	32GB or 64GB eMMC
Display Resolution	1920 x 1080 (Full HD)
Ports	USB-C, USB-A, Headphone/Microphone combo
Wireless	Bluetooth 5.0
